Question? What Is The Absolute Best Tail System?

Discussion in 'The Chat Room' started by smakmeharder, Oct 23, 2014.

By smakmeharder on Oct 23, 2014 at 9:41 AM
  1. smakmeharder

    smakmeharder Administrator

    Joined:
    Mar 3, 2014
    Messages:
    4,825
    Likes Received:
    3,096
    I have seen a few different tail setups in the past. So i am wondering what is the absolute best performing tail system out there.

    The new Align tail system looks good.



    There there is the Heneselit tail system


    Vortex Tail System

    MH-VT2026D_l.jpg MH-VT2142DTS_l.jpg

    Alees Rush 750


    So are there any other unique designs you can think of and which system is the superior one?


Comments

Discussion in 'The Chat Room' started by smakmeharder, Oct 23, 2014.

    1. Manyc

      Manyc Well-Known Member

      Joined:
      Mar 14, 2014
      Messages:
      1,619
      Likes Received:
      1,189
      Lol tail blades hum has long been shown to be caused by the tail blades.. not the bell crank

    2. utrinque

      utrinque Well-Known Member

      Joined:
      Jul 19, 2014
      Messages:
      557
      Likes Received:
      310
      Sure. I use cheap $4 105mm CF tail blades and do not have tail hum.

      Some say it is related to TT... Actually nobody really knows what is going on with it so we probably talk about some harmonic vibes.

      My friend had Goblin 700. Crashed it hard in 9th flight and did not rebuild. Cost of rekit was high. He got Agile 7.2 instead. He had problems with it. Mainly related to weak belt and smaller pinion he used. He is strugling with Chase, he likes X3.

      Out of big birds he put 800mm blades on Assault like me and we both did not have problems with mechanics for months. It is not fancy nor very expensive heli but tail is rock solid at higher RPM.

      Actually RPM and proper gearing seems crucial at bigger helis. Not servo, not gyro, not mechanics but RPM of main and tail rotor can influence tail performance most. That is just my experience.

      One of my colleagues sold TDR because he likes high RPMs and smack. TDR gearing seems to work better at lower RPMs. He did not like tail performance at high RPMs.

      I use realatively cheap electronics and parts. They did not fail on me with two exceptions this season:

      I had really bad crash of my 800 related probably to radio signal loss. My fault I placed antenna to close to main frame. High speed, no TH, nose into the mother earth. I was surprised I lost only main blades, $4 plastic canopy and three plastic ball links. Other parts were intact except slightly bent main shaft I replaced and slightly bent tail boom I still use after streightening it up.

      Once overtightened bolt mounting tali grip broke. My fault. Never use excessive force to tighten such bolts. Use spacers. This time I performed perfect autorotation and did not even break landing gear.

      Sorry for off topic.

      Last edited: Oct 25, 2014
    3. jockstrap

      jockstrap Active Member

      Joined:
      Apr 3, 2014
      Messages:
      347
      Likes Received:
      212
      A good Tail system should have counterweighted grips - so easy to do.. .not sure why hardly anyone is doing it..

      Align started doing it for a while on the 450s but seem to have fallen off doing them too?

      The counterweights dramatically lower the load on the tail servo... so unless there is an adverse effect I'm unaware of, why aren't they all using them ?


    4. utrinque

      utrinque Well-Known Member

      Joined:
      Jul 19, 2014
      Messages:
      557
      Likes Received:
      310
      Last edited: Oct 25, 2014
    5. jockstrap

      jockstrap Active Member

      Joined:
      Apr 3, 2014
      Messages:
      347
      Likes Received:
      212
      Yea - I call them "Chinese Weights" also but wasn't sure if that was the real name or not..

    6. Jeff_Bradley

      Jeff_Bradley Well-Known Member

      Joined:
      Mar 14, 2014
      Messages:
      778
      Likes Received:
      611
      There is no crime in being a rush fan boy, the crime is overlooking them. Peace out


      Sent from my iPhone using Tapatalk

    7. mr_squiggle

      mr_squiggle Well-Known Member

      Joined:
      Apr 29, 2014
      Messages:
      582
      Likes Received:
      379
      'Twas just a gentle wind up Jeff.
      @feral can like what ever he wants, I'm not worried in the slightest.


      Citizen #186

      • Like Like x 1
      • Informative Informative x 1
      • List
    8. feral

      feral Well-Known Member

      Joined:
      Mar 14, 2014
      Messages:
      2,299
      Likes Received:
      1,461
      Except for dji phantoms if I ever buy 1 y'all have permission to shoot at will

    9. mr_squiggle

      mr_squiggle Well-Known Member

      Joined:
      Apr 29, 2014
      Messages:
      582
      Likes Received:
      379
      Ok you can be the second shot after we blow the Phantom out of the sky.


      Citizen #186

    10. feral

      feral Well-Known Member

      Joined:
      Mar 14, 2014
      Messages:
      2,299
      Likes Received:
      1,461
      Sounds bloody good to me pencilnose

    11. gonehelimad

      gonehelimad Active Member

      Joined:
      Feb 28, 2015
      Messages:
      285
      Likes Received:
      234
      Have been reading about rc-tek tail grips which are available for most size helis and their ability allow the servo to work more efficiently and to improve tail holding power by evening out the forces
      Thinking about getting a set of the below to improve my tail performance. Lot of people who have used them on Trex have claimed big tail performance improvements.
      http://www.rc-tek.com/store/i2rc-hi...-blade-tail-grip-assembly-with-hub-p2320.html


      The logic being their design and ability to improve tail holding / performance is that a normal grip will naturally want to spin with zero pitch on the blades. To twist the blades away from zero pitch requires an increasing amount of force. The chinese weights change the moment of inertia, so that the force required to rotate the blades changes much less over their range of travel. Therefore, your tail servo doesn't have to work so hard, and can respond faster to required pitch changes.


      Here are some videos showing the improvement that a chinese weights approach design provides.


      Thoughts?

    12. utrinque

      utrinque Well-Known Member

      Joined:
      Jul 19, 2014
      Messages:
      557
      Likes Received:
      310
      Actually SAB copied 1:1 all tail diameters from Align. Align parts will fit Goblin tail.

      (This info comes from Benji. He had G700 and now has second Goblin 700 Competition.)

    13. ScottE

      ScottE Active Member

      Joined:
      Mar 21, 2014
      Messages:
      138
      Likes Received:
      99
      @gonehelimad Chinese weights are standard on tge avant mostro .. must be one of the tuffest yet still smooth tails ive owned (srimrok faifa still holds the mantle )

    14. utrinque

      utrinque Well-Known Member

      Joined:
      Jul 19, 2014
      Messages:
      557
      Likes Received:
      310
      Kasama kept my attention for a long time. It looks like jewelry job.

      I wonder why it is so rare.

      Probably:
      - price tag
      - over ingeeneering, very high parts count
      - ugly shape of canopy :) this is subjective I do not like it.
      - frame looks very fragile
      - lack of global parts availability

      I wonder if they really use exceptional materials.

      Looking at photos it definitely stands out of the crowd.

      I would love to flight check one.

    15. ScottE

      ScottE Active Member

      Joined:
      Mar 21, 2014
      Messages:
      138
      Likes Received:
      99
      @utrinque I had a 2 year love affair with the faifa owning 3 off them .. all destroyed in high speed crashes -230kmh frames are the sacrificial piece and from memory around $99au each . That +parts here in oz was the biggest issue . Yes they do use titanium bolts etc and it was over engineered but who doesnt like that ! Really stood out in the crowd & was the fastest thing on the planet at one stage . mine clocked 238kmh .
      One thing that was an issue .. the small tsil boom used to flex & I had a mad vibration issue in the tail drive I couldnt sort ... off to the big knackery in the sky (stripped and sold as parts to fund my current gauix7

      • Like Like x 1
      • Informative Informative x 1
      • List
    16. Retssaf

      Retssaf Member

      Joined:
      Mar 18, 2014
      Messages:
      23
      Likes Received:
      34
      after trying Align , Synergy , SAB,JR,Kasama,TDR,Banshee and Mikado

      Mikado Logo 700 Xxtreme tail knocks all of the above out of the ball park , so solid and such a beautiful feel its amazing . gives such confidence to really push .

    17. HungryHungryHippos

      HungryHungryHippos Well-Known Member

      Joined:
      Mar 14, 2014
      Messages:
      290
      Likes Received:
      235
      Ive only got a poor little logo xxtreme 480. But tail sure holds well.

    18. utrinque

      utrinque Well-Known Member

      Joined:
      Jul 19, 2014
      Messages:
      557
      Likes Received:
      310
      Did you fly the same RPM, tail gear ratio, same tail servo and FBL unit? Did you use governor? It can deteriorate tail performance.

    19. utrinque

      utrinque Well-Known Member

      Joined:
      Jul 19, 2014
      Messages:
      557
      Likes Received:
      310
    20. Retssaf

      Retssaf Member

      Joined:
      Mar 18, 2014
      Messages:
      23
      Likes Received:
      34
      1 have 3 banks setup on every heli with 3 different headspeeds , only ever used Vbar and I use Ksomik gov , its all about getting the right motor and gearing for the job .
